DELL PRO THUNDERBOLT 4SMART DOCK SD25TB4 Connectivity Technology: Wired |
|
Number of Displays Supported: 4 |
|
Host PC Management: Intel AMT over Thunderbolt with select Intel vPro PCs |
|
MAC address pass-through |
|
PXE Boot Dock Power Button Sync |
|
Wake-On-LAN |
|
WLAN to LAN switch |
|
Kernel Direct Memory Access (DMA) protection |
|
Dock Management Features: Remote firmware updates without a PC |
|
Host-based firmware updates |
|
Firmware update on disconnect |
|
Port Disablement independent of PC |
|
Device Supported: Notebook |
|
Video Resolution: DP1.4 / DP2.1 with Display Stream Compression Up to: |
|
4 x 4K (3840x2160) 60Hz |
|
3 x 4K (3840x2160) 60Hz |
|
2 x 6K (6144 x 3456) 60Hz |
|
1 x 8K (7680 x 4320) 60Hz |
|
DP1.4 without Display Stream Compression Up to: 4 x QHD (2560x1440) 60Hz |
|
3 x WQHD (3440 x 1440) 60Hz |
|
2 x 4K (3840x2160) 60Hz |
|
1 x 5K WUHD (5120 x 2160) 60Hz |
|
Ethernet Technology: RJ45 Ethernet port |
|
2.5GbE |
|
Interfaces: Video interfaces: 2 x DP1.4 |
|
1 x HDMI 2.1 |
|
1 x USB-C 3.2 Gen 2 Multi-function DisplayPort 1.4 |
|
2 x Thunderbolt 4 |
|
USB Ports (Power): 4 x USB-A 3.2 Gen 2 (4.5W each) |
|
1 x USB-C 3.2 Gen 2 (15W) |
|
1 x USB-C Multi-function DisplayPort (7.5W) |
|
2 x Thunderbolt 4 (15W each) |
|
All deliver power with or without PC |
|
USB Power Delivery: 130W (Dell systems) |
|
96W (non-Dell systems) |
|
USB Ports (Data Only): 4 x USB-A 3.2 Gen 2 (10 Gbps): 1 x USB- C 3.2 Gen 2 (10 Gbps) |
|
Operating System Supported: Windows 10 |
|
Windows 11 |
|
Ubuntu |
|
Red Hat Enterprise Linux |
|
ChromeOS |
|
macOS |
|
Maximum Power Supply Wattage: 180W |
|
Kensington Security Slot: Yes |
|
Limited Warranty: 3 Year |
