Descriere
Performanță |
| Connectivity technology | Wired |
| Type | IP security camera |
| Placement supported | Outdoor |
| Certification | CISPR 24, CISPR 35, EN 50121-4, EN 55024, EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), IEC 62236-4, KC KN32 Class A, KC KN35, RCM AS/NZS CISPR32 Class A, VCCI Class A, IEC/EN/UL 60950-22, IEC/EN/UL 62368–1, IEC 60068-2-1, IEC/EN 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC/EN 60068-2-78, IEC/EN 60529 IP66/IP67, IEC/EN 62262 IK10b , ISO 21207 Method B, MIL-STD-810H (Method 501.7, 502.7, 505.7, 506.6, 507.6, 509.7, 510.7, 514.8, 516.8, 521.4), NEMA 250 Type 4X, NEMA TS 2 (2.2.7–2.2.9), NIST SP500-267 |
| Languages support | ENG,POL,ESP,ITA,POR,JPN,RUS,CHI (SIMPL),FRE,KOR,CHI (TR),DEU |
| Number of languages | 13 |
| Thermal module | Yes |
Design |
| Product colour | Black,White |
| Form factor | Bullet |
| Mounting type | Wall/Pole |
| International Protection (IP) code | IP65, IP67 |
| Housing material | Aluminium,Polycarbonate (PC) |
| IK code | IK10 |
Aparat de fotografiat |
| Lens viewing angle, horizontal | 63 ° |
Senzor de imagine |
| Sensor type | Microbolometer |
| Number of sensors | 1 |
| Effective sensor resolution (thermal module) | 640 x 480 pixels |
Sistem de lentile |
| Maximum aperture number | 1.17 |
| Number of lenses | 1 |
| Closest focusing distance | 2.8 m |
| Lens diameter | 10 mm |
Video |
| Maximum resolution | 800 x 600 pixels |
| Frame rate | 30 fps |
| Image quality adjustment | Brightness,Contrast,Sharpness |
| Video streaming | Yes |
| Text caption overlay | Yes |
| Bit rate control | Variable Bit Rate (VBR) |
| Image stabilizer | Yes |
| Video formats supported | H.264,H.265,AVC,MPEG4,HEVC,M-JPEG |
| Gain control type | Auto |
Audio |
| Audio formats supported | G.711,G.726,AAC-LC,LPCM,ADPCM,PCM |
| Audio system | 2-way |
Reţea |
| Ethernet LAN | Yes |
| Supported network protocols | IPv4, IPv6 USGv6, HTTP, HTTPS, HTTP/2, SSL/TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP , SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, RTCP, DHCPv4/v6, SOCKS, SSH, LLDP, MQTT v3.1.1, Syslog |
| Networking standards | IEEE 802.3af,IEEE 802.3at |
| Ethernet interface type | Fast Ethernet,Gigabit Ethernet |
| Quality of Service (QoS) support | Yes |
Medii de stocare |
| Compatible memory cards | MicroSD (TransFlash),MicroSDHC,MicroSDXC |
| Card reader integrated | Yes |
| Flash memory | 512 MB |
| Internal memory | 1024 MB |
Conexiune |
| Ethernet LAN (RJ-45) ports | 1 |
| Microphone in | Yes |
| Terminal block port | Yes |
Securitate |
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Password protection | Yes |
| Security algorithms | EAP-TLS |
| Alert notification type | E-mail |
| Digest authentication | Yes |
Managementul energiei |
| Power source type | DC,PoE |
| Power consumption (typical) | 5.4 W |
| Power consumption (max) | 12.95 W |
| DC output voltage | 12,28 |
Conditii de mediu |
| Operating temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 10 - 100 % |
| Storage temperature (T-T) | -40 - 65 °C |
Greutate ÅŸi dimensiuni |
| Weight | 1400 g |
| Height | 132 mm |
| Width | 132 mm |
| Depth | 272 mm |
Conţinutul de ambalaje |
| Number of cameras | 1 |
| Mounting kit | Yes |
| Manual | Yes |
| Sun shield included | Yes |
Detalii tehnice |
| Doesn''t contain | PVC/BFR |
Date logistice |
| Harmonized System (HS) code | 85258900 |
